Contains data required to perform a scatter interaction. More...
#include <ContinuousReaction.hpp>
Public Member Functions | |
| ContinuousScatter (const pugi::xml_node &scatter_node) | |
Constructs ContinuousScatter from a scatter node of an XML document, loading thermal scattering data if found. | |
| bool | ModifiesTotal (const Particle &p) const noexcept override |
| Returns true if thermal scattering is present. More... | |
| MicroscopicCrossSection | GetMajorant (const Particle &p) const noexcept override |
| Returns largest scattering cross section that may be found within the current Cell. More... | |
| MicroscopicCrossSection | GetCrossSection (const Particle &p) const noexcept override |
| Returns appropriately-adjusted scattering cross section. More... | |
| void | Interact (Particle &p) const noexcept override |
| Scatter the Particle. More... | |
 Public Member Functions inherited from ContinuousReaction | |
| ContinuousReaction (const pugi::xml_node &reaction_node) | |
| Constructs ContinuousReaction from a reaction node of an XML document. | |
| virtual | ~ContinuousReaction () noexcept |
| Virtual destructor (C++ Core Guidelines C.127) | |
| virtual bool | ModifiesTotal (const Particle &) const noexcept |
| Returns true if the reaction's cross section will change the total cross section. More... | |
| virtual MicroscopicCrossSection | GetMajorant (const Particle &p) const noexcept |
| Returns the largest cross section that may be found within the current Cell. More... | |
| virtual MicroscopicCrossSection | GetCrossSection (const Particle &p) const noexcept |
| Returns temperature-adjusted cross section for the reaction. More... | |
| virtual void | Interact (Particle &p) const noexcept=0 |
| Interact with a Particle, updating its state. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from ContinuousReaction | |
| static std::unique_ptr< const ContinuousReaction > | Create (const pugi::xml_node &reaction_node) |
| Factory method to create a new ContinuousReaction from an XML document. | |
| Protected Attributes inherited from ContinuousReaction | |
| const ContinuousEvaluation | evaluation |
| Cross section data associated with reaction. | |
Detailed Description
Contains data required to perform a scatter interaction.
Additional data on scattering methods is available on Transport Methods
Member Function Documentation
◆ GetCrossSection()
|
overridevirtualnoexcept |
Returns appropriately-adjusted scattering cross section.
Thermal neutron scattering is assumed to encompass both elastic and inelastic scattering. Performs temperature adjustments from free gas or thermal scattering, if applicable.
Reimplemented from ContinuousReaction.
◆ GetMajorant()
|
overridevirtualnoexcept |
Returns largest scattering cross section that may be found within the current Cell.
Used when there is a continuous dependence on temperature. Performs temperature adjustments from free gas or thermal scattering, if applicable.
Reimplemented from ContinuousReaction.
◆ Interact()
|
overridevirtualnoexcept |
Scatter the Particle.
- Todo:
- Compute \( \mu \) more directly in free gas scattering. Find analytic expression to avoid dot product between incident neutron velocity and outgoing neutron velocity when calling Particle::Scatter.
Implements ContinuousReaction.
◆ ModifiesTotal()
|
overridevirtualnoexcept |
Returns true if thermal scattering is present.
Reimplemented from ContinuousReaction.
The documentation for this class was generated from the following file:
- /Users/atumulak/Developer/minimc/src/ContinuousReaction.hpp
